DLDZ-MD801 Analog circuit experiment box

Model: DLDZ-MD801 Analog circuit experiment box

2.1. Power input

Single-phase three-wire AC power AC220V±10% 50Hz

2.2 ±5V continuous adjustable DC voltage source

Inquire Now

DLDZ-MD801 Analog circuit experiment box

Details introduction

Overview

The Portable Analog circuit experiment box is developed based on the basic courses and teaching requirements about electronic technology training course in vocational schools, engineering universities and colleges, the experiment training model is mainly used to training of electronics analog circuits, electronic technology foundation and the basic experiment teaching instrument of curriculum designing.

Configuration

Analog circuit experimentation consists of single/double double tube, differential amplifier, integrated operational amplifier, rectifier, filter, voltage regulator circuit, FET amplifier circuit, crystal oscillator circuit and so on. At the same time, the extended experimentation area of portable electronics training box is composed of horn, universal lock socket, bread plate, plurality of resistors, capacitor, diode and triode, equal socket, etc.

Training projects

- Single stage amplifier circuit

-Two stage amplifier circuit

-Negative feedback amplifying circuit

-Emitter follower

- Common Emitter

-Common Collector

- Common B

-Complementary symmetry power amplifier

- Basic parameters test of integrated operational amplifier

-Integrated addition operation circuit

- Integrated subtract circuit
